IMER Pump & Spraying Machine | 24 HP | Silent 300 Prestige 1106133

The Silent 300 Prestige is a robust and versatile diesel-powered pump and spray machine designed for demanding construction and industrial applications. Featuring a 24hp Yanmar diesel engine, a built-in 6.3 cubic foot hydraulic mixer, and an onboard compressor for spraying, this machine is designed to handle heavy-duty tasks with ease. Whether you're spraying, pumping, or mixing, the Silent 300 Prestige combines all the features you need in one efficient, towable unit. With the ability to work with a variety of rotor/stator combinations, it's the ideal solution for pumping materials with up to 3/8" aggregate.

Specifications:

• Engine: Diesel Yanmar, 24 hp

• Compressor Flow Rate: 14 cf/m

• Max Pumpable Aggregate Size (IM25L): 3/8"

• Variable Flow Rate (60.12”): 6 yd/hr

• Variable Flow Rate (IM25L): 4 yd/hr

• Variable Flow Rate (2L6): 3 yd/hr

• Max Pressure (2L6): 580 psi

• Hopper Capacity: 7 cu ft

• Mixer Capacity: 6.3 cu ft

• Dimensions: 131-½” W x 55-½” L x 53” H

• Weight: 1,653 lbs

Key Features:

• Powerful Diesel Engine: Equipped with a 24 hp Yanmar diesel engine, this pump and spray machine is built for high-demand applications, ensuring reliable performance and efficiency.

• Hydraulic Mixer & Compressor: The built-in hydraulic mixer (6.3 cu ft capacity) and onboard compressor (14 cf/m flow rate) allow for seamless pumping and spraying, saving time and effort on the job site.

• High Capacity Hopper: The 7 cu ft hopper can handle large batches, allowing for continuous operation without frequent refills.

• Pressure & Flow Control: With a maximum pressure of 580 psi and variable flow rates, you can adjust the output to suit various materials and application needs.

• Safety Features: The safety sensor system automatically stops the mixing paddles when the grid is opened, ensuring safe operation at all times.

• Articulating Towbar: Designed to tow the machine safely and level, ensuring smooth transportation across job sites.

• Versatility: Includes an adjustable 2L6 rotor/stator, allowing you to pump a variety of materials with ease.

Standard Equipment:

• 24 HP Yanmar Diesel Engine: For powerful and continuous operation.

• 14 CF/m Compressor: Provides optimal airflow for spraying tasks.

• 2L6 Screw Pump: Reliable and efficient for continuous pumping.

• 2 Clean-out Sponges: Makes cleanup easier and more efficient.

• High Shear Hydraulic Mixer: For uniform and consistent material mixing.

• Variable Speed Hydraulic Pump: Allows for precise control over material flow.

• Programmable Mixer Timer: For better control over mixing cycles.

• Metal Accessory Box: For convenient and organized storage of accessories.

• Tow Package for Highway Use: Ensures easy and safe transport of the machine.

Optional Equipment:

• 33" of 35mm Hose (Part # 1107528)

• 33" of 50mm Hose (Part # 1107533)

• Aqua Control Electronic Meter System (Part # 1107209)

• Vibrating Grate (Part # 1107036)

• 164" Remote Control (Part # 1107086)

• IM25L Rotor/Stator Kit (Part # 1107149)

• 60.12 Rotor/Stator Kit (Part # 1107090)

• L7-1.5 Rotor/Stator Kit (Part # 1107660)

• 50mm to 35mm Material Hose Reducer (Part # 1106178)

• Spray Gun Step 120 (Part # 1107577)

• 16" x 35mm Male to 25mm Male Hose (Part # 1107074)

• Pintle Tow Ring (Part # 1107161)

• Shotcrete Gun (Part # 1106250)

• 5" Overhead Wand (Part # 1107549)

Why Choose the Silent 300 Prestige?

• Heavy-Duty Diesel Power: The Yanmar 24hp engine provides the power needed for large-scale projects and continuous operation.

• Complete Pumping and Spraying Solution: With an integrated hydraulic mixer, compressor, and versatile rotor/stator options, this machine is designed to handle a wide variety of materials and applications.

• Ease of Use: The military-spec control panel integrates all functions in one location, simplifying operation and making the Silent 300 Prestige easy to use for operators of all skill levels.

• Safe and Efficient: The built-in safety features and high-capacity hopper ensure that you can work without interruptions while maintaining a safe work environment.

• Compact and Towable: Despite its power, the Silent 300 Prestige is designed for easy transport, featuring a tow package that meets highway standards.
