BMP.3200.IR Platinum Sliding Panel Saw
Precision, Power, and Performance for Your Workshop
The BMP.3200.IR Platinum is the most powerful sliding panel saw in our lineup, designed for precision and efficiency. Powered by a 7.5HP main motor and a ¾ HP scoring motor (3-phase), this industrial-grade saw delivers seamless cutting performance.
The 126” anodized aluminum sliding table glides effortlessly on precision linear guide rails, providing ultra-smooth movement for accurate cuts. The European-style 51” rip fence features a digital readout with micro-adjustments for fine-tuned accuracy. Simply lock it in place and adjust incrementally for a perfect fit.
With a heavy-duty anodized aluminum crosscut fence, dual flip-stops, and a telescoping function (max 140”), the BMP.3200.IR Platinum ensures precision on every cut. The overhead CE blade guards (90° and 45°) feature a quick-change, swing-away function, making adjustments a breeze.
Key Features
- High-Power Performance – 7.5 HP main motor (4000 RPM) with a ¾ HP scoring motor (8000 RPM).
- Tilting Saw Blade (90°-45°) – Digital blade angle display for precise adjustments.
- Ultra-Smooth Sliding Table – 126” anodized aluminum table runs on precision linear guide rails.
- Heavy-Duty Rip Fence – 51” European-style rip fence with digital readout and micro-adjustments.
- Precision Crosscut Fence – Telescoping to 140”, with two solid flip-stops and a 45° miter function.
- Advanced Safety & Dust Control – Overhead blade guards (90° & 45°) with quick-change function.
- Complete Cutting Solution – Includes push handle, hold-down clamp, and wedge clamp.
- 2-Year Warranty – Backed by industry-leading support and durability.
Specifications
| Specification | SAE | Metric |
|---|---|---|
| Main Motor | 7.5 HP / 4000 RPM, 5.5 kW | 5.5 kW, 4000 RPM |
| Blade Diameter | 12" (305 mm) – Max 14" (355 mm) | 305 mm – Max 355 mm |
| Main Blade Cutting Height (90°) | 3 ½" | 90 mm |
| Main Blade Cutting Height (45°) | 2 7/16" | 63 mm |
| Scoring Motor | ¾ HP / 8000 RPM, 0.74 kW | 0.74 kW, 8000 RPM |
| Scoring Blade Diameter | 4 ¾" | 120 mm |
| Max Ripping Capacity | 51" | 1295 mm |
| Crosscut Capacity | 126" | 3200 mm |
| Dust Collection Ports | (2) 4" | 100 mm |
| Electrical Specs | 3 Phase 220V, 30 Amps, 60 Hz | 3 Phase 220V, 30 Amps, 60 Hz |
| Machine Dimensions (LxWxH) | 132" x 137" x 75" | 3352 x 3479 x 1905 mm |
| Weight (Net/Gross) | 1470 lbs / 667 kg | 667 kg |
Built for professional woodworkers, cabinet shops, and high-production environments, the BMP.3200.IR Platinum redefines precision cutting. Elevate your workshop with this industry-leading sliding panel saw today!
Description
BMP.3200.IR Platinum Sliding Panel Saw
Precision, Power, and Performance for Your Workshop
The BMP.3200.IR Platinum is the most powerful sliding panel saw in our lineup, designed for precision and efficiency. Powered by a 7.5HP main motor and a ¾ HP scoring motor (3-phase), this industrial-grade saw delivers seamless cutting performance.
The 126” anodized aluminum sliding table glides effortlessly on precision linear guide rails, providing ultra-smooth movement for accurate cuts. The European-style 51” rip fence features a digital readout with micro-adjustments for fine-tuned accuracy. Simply lock it in place and adjust incrementally for a perfect fit.
With a heavy-duty anodized aluminum crosscut fence, dual flip-stops, and a telescoping function (max 140”), the BMP.3200.IR Platinum ensures precision on every cut. The overhead CE blade guards (90° and 45°) feature a quick-change, swing-away function, making adjustments a breeze.
Key Features
- High-Power Performance – 7.5 HP main motor (4000 RPM) with a ¾ HP scoring motor (8000 RPM).
- Tilting Saw Blade (90°-45°) – Digital blade angle display for precise adjustments.
- Ultra-Smooth Sliding Table – 126” anodized aluminum table runs on precision linear guide rails.
- Heavy-Duty Rip Fence – 51” European-style rip fence with digital readout and micro-adjustments.
- Precision Crosscut Fence – Telescoping to 140”, with two solid flip-stops and a 45° miter function.
- Advanced Safety & Dust Control – Overhead blade guards (90° & 45°) with quick-change function.
- Complete Cutting Solution – Includes push handle, hold-down clamp, and wedge clamp.
- 2-Year Warranty – Backed by industry-leading support and durability.
Specifications
| Specification | SAE | Metric |
|---|---|---|
| Main Motor | 7.5 HP / 4000 RPM, 5.5 kW | 5.5 kW, 4000 RPM |
| Blade Diameter | 12" (305 mm) – Max 14" (355 mm) | 305 mm – Max 355 mm |
| Main Blade Cutting Height (90°) | 3 ½" | 90 mm |
| Main Blade Cutting Height (45°) | 2 7/16" | 63 mm |
| Scoring Motor | ¾ HP / 8000 RPM, 0.74 kW | 0.74 kW, 8000 RPM |
| Scoring Blade Diameter | 4 ¾" | 120 mm |
| Max Ripping Capacity | 51" | 1295 mm |
| Crosscut Capacity | 126" | 3200 mm |
| Dust Collection Ports | (2) 4" | 100 mm |
| Electrical Specs | 3 Phase 220V, 30 Amps, 60 Hz | 3 Phase 220V, 30 Amps, 60 Hz |
| Machine Dimensions (LxWxH) | 132" x 137" x 75" | 3352 x 3479 x 1905 mm |
| Weight (Net/Gross) | 1470 lbs / 667 kg | 667 kg |
Built for professional woodworkers, cabinet shops, and high-production environments, the BMP.3200.IR Platinum redefines precision cutting. Elevate your workshop with this industry-leading sliding panel saw today!
