Smooth Operation, Enhanced Comfort: EKKO EK25SLP Liquid Propane Forklift
The EKKO EK25SLP Liquid Propane Forklift is a comfortable and efficient solution for various material handling tasks in warehouses and distribution centers. Here's what makes the EK25SLP stand out:
Operator Comfort and Reduced Fatigue:
- Spacious Operator Compartment: An enlarged operating space with a heightened overhead guard offers ample room for operators of various sizes. The large arc design of the front overhead guard legs provides additional headroom.
- Enhanced Seating: A semi-suspension seat with a small steering wheel promotes a comfortable driving posture. Electro-hydraulic direction changing and automobile-style double combined switches minimize hand and arm strain.
- Reduced Vibration: The cushion connection and fully suspended cab effectively absorb vibrations from the forklift, minimizing operator fatigue during long shifts. Additionally, a damping device in the lifting system reduces mast shock and vibration, further reducing noise and discomfort.
Efficient Performance and Maneuverability:
- Tighter Turning Radius: Allows for exceptional maneuverability in tight warehouse spaces.
- Optimized Hydraulic System: The hydraulic system is designed for energy efficiency, resulting in lower fuel consumption and potentially reduced operating costs.
- Tier 4 EPA and CARB 4 Compliant Engine: The EK25SLP adheres to strict environmental regulations while delivering reliable power.
Specification
|
Model |
|
EK25SLP |
|
Drive type |
|
LPG |
|
Type of operation |
|
Propane |
|
Load Capacity |
LBS |
5000 |
|
Load Center |
in |
24 |
|
Lift height |
in |
189 |
|
Wheelbase |
in |
58 |
|
Service Weight |
LBS |
9370 |
|
Tire material |
|
Pattern Cushion Tire |
|
Wheel size(Front / Rear) |
in |
21x7-15/16x6-10.5 |
|
Service Brake |
|
Hydraulic Floor Pedal |
|
Overall width |
in |
42 |
|
Overall length with forks |
in |
136.8 |
|
Overall length without forks |
in |
94.5 |
|
Min ground clearance (at the mast) |
in |
3.5 |
|
Max traveling speed (loaded/unloaded) |
mph |
10.8/10.8 |
|
Mast Overall height |
in |
85 |
|
Free lifting height |
in |
44 |
|
Backrest height (from the surface of the forks) |
in |
40 |
|
Fork Size |
in |
42x4.8x1.57 |
|
Battery |
V/ Ah |
12/60 |
|
Engine Mode |
|
Mitsubishi 4G64 (PSI Engine) |
|
Engine rated power |
HP/rpm |
LPG: 63/2700 |
Description
Smooth Operation, Enhanced Comfort: EKKO EK25SLP Liquid Propane Forklift
The EKKO EK25SLP Liquid Propane Forklift is a comfortable and efficient solution for various material handling tasks in warehouses and distribution centers. Here's what makes the EK25SLP stand out:
Operator Comfort and Reduced Fatigue:
- Spacious Operator Compartment: An enlarged operating space with a heightened overhead guard offers ample room for operators of various sizes. The large arc design of the front overhead guard legs provides additional headroom.
- Enhanced Seating: A semi-suspension seat with a small steering wheel promotes a comfortable driving posture. Electro-hydraulic direction changing and automobile-style double combined switches minimize hand and arm strain.
- Reduced Vibration: The cushion connection and fully suspended cab effectively absorb vibrations from the forklift, minimizing operator fatigue during long shifts. Additionally, a damping device in the lifting system reduces mast shock and vibration, further reducing noise and discomfort.
Efficient Performance and Maneuverability:
- Tighter Turning Radius: Allows for exceptional maneuverability in tight warehouse spaces.
- Optimized Hydraulic System: The hydraulic system is designed for energy efficiency, resulting in lower fuel consumption and potentially reduced operating costs.
- Tier 4 EPA and CARB 4 Compliant Engine: The EK25SLP adheres to strict environmental regulations while delivering reliable power.
Specification
|
Model |
|
EK25SLP |
|
Drive type |
|
LPG |
|
Type of operation |
|
Propane |
|
Load Capacity |
LBS |
5000 |
|
Load Center |
in |
24 |
|
Lift height |
in |
189 |
|
Wheelbase |
in |
58 |
|
Service Weight |
LBS |
9370 |
|
Tire material |
|
Pattern Cushion Tire |
|
Wheel size(Front / Rear) |
in |
21x7-15/16x6-10.5 |
|
Service Brake |
|
Hydraulic Floor Pedal |
|
Overall width |
in |
42 |
|
Overall length with forks |
in |
136.8 |
|
Overall length without forks |
in |
94.5 |
|
Min ground clearance (at the mast) |
in |
3.5 |
|
Max traveling speed (loaded/unloaded) |
mph |
10.8/10.8 |
|
Mast Overall height |
in |
85 |
|
Free lifting height |
in |
44 |
|
Backrest height (from the surface of the forks) |
in |
40 |
|
Fork Size |
in |
42x4.8x1.57 |
|
Battery |
V/ Ah |
12/60 |
|
Engine Mode |
|
Mitsubishi 4G64 (PSI Engine) |
|
Engine rated power |
HP/rpm |
LPG: 63/2700 |
